This 20-inch heavy-duty true line perforator has been designed for quality, high production, precision perforating, as well as scoring and slitting on stocks ranging from 9 lb. manifold to 1/16″ board.

Rosback has been providing world class perforating and slitting solutions since 1881. The TrueLine feeding mechanism is so consistent that it is copied by many folder manufacturers wanting continuous, accurate feeding of various weights of paper. TrueLine Perforators provide a high quality, cost-effective perforating and scoring solution that presses or folders cannot match.

Enjoy a wide variety of uses including Slot, Knife-Cut and Micro Perforation, Slitting, and Scoring. Get precision results on stocks ranging from 9-lb. onionskin to 1/16” board. Rosback TrueLines are well known for simplicity of use and years of trouble free operation.

FEATURES

• Perforating heads with built-in chip removers
• Stripper-completely surrounding perforating cutters
• Molded drive rollers
• See-through safety cover
• Heads can be quickly added or removed
• Up to 5 perforating heads can be used on 20″ machine*

* Greatly depends on stock to be run.

SPECIFICATIONS

• Maximum sheet size: 20″ W x 23″ L
• Minimum sheet size: 3″ W x 3″ L
• Minimum space between standard lines of perforation: 3/4″
• Standard edge margin: 3/4″
• Length, front to back: 55″
• Width, side to side: 32″
• Height: 42″
• Net weight: 275 lbs
• Shipping weight: 366 lbs
• Standard electrics (friction): 115v/60hz/1ph/5amps

Export & Dealer Pricing – Is available, please contact us for details

Spanish / Español Support – Equipo de Apoyo que Hablan Español de PFS
